S-DXC Motor Protection Relay

Current Range

  • 0.25 TO 5 Amp
  • 0.8 TO 5 Amp
  • 4 TO 61 Amp
  • 40 TO 500 Amp
  • 400 TO 1200 Amp

Manufacturer of a wide range of products which include DXC-M92 Motor Protection Relay, EXC-M92 Motor Protection Relay, S-DXC Motor Protection Relay, S-DXA Motor Protection Relay, S-EC Motor Protection Relay And DXC Motor Protection Relay.

Product Details:

Aux Supply : 110 VAC OR 230 VAC OR 415 VAC
CT Type : In built Phase CTs up to 61 A & External Phase CTs above 61 A
Voltage Type : AC
Temperature : +10 TO 60 Degree C [Operation]
Display : Current Through 7 Segment LED
Mounting : Device DIN Rail Mount / Display Door Mount [Door Cutout 70 X 30 mm]

Standard Features:

  • Selectable IT Curve OR Definite Time
  • Selectable Trip Time for SPP & UL
  • Selectable Rotor Locked Value

Optional Feature :

  • Separate Relay for U/L Protection
  • 4 to 20mA Output
  • Two Separate Relay output available

Protections

  • Single Phasing Protection
  • Over Load Protection
  • Under Load Protection
  • Phase-reversal Protection
  • Phase Un-balance
  • Locked Rotor Protection
  • Short Circuit Protection
  • Earth Fault Protection

Annunciations

  • SPP
  • O
  • U
  • Ph-r
  • b
  • L
  • S
  • E
